Extrusion, rolled form, corners, spline, by the piece.
Screen Frame and Components
When it comes to screens, Connecticut Enclosures & Screens can help you stand out against the competition with a range of sizes, finishes, meshes and performance capabilities. Aluminum screen frame is available cut to size in several profiles and colours. The standard 3/4" wide frame suits lighter materials like fiberglass screen and aluminum screen wire.
We reply to every message within one business day.
Extruded and rolled formCut to size12' shipping lengthsTrade quantities
Extruded frames
1 · Extruded screen frame 5/16 × 3/4"
- Material thickness
- .025
- Shipping length
- 12'
- Finishes
- Almond, bronze, mill, white, Hartford green
- Best for
- Jobs where larger sizes are required
2 · Extruded screen frame 7/16 × 1"
- Material thickness
- .062
- Shipping length
- 12'
- Finishes
- White, bronze, clear satin anodized
- Best for
- Larger window openings and commercial applications
Rolled form frames
3 · Rolled form 5/16 × 3/4"
- Material thickness
- .0155
- Best for
- Screen fabrication
4 · Rolled form 7/16 × 3/4"
- Material thickness
- .0155
- Standard length
- 12' 2"
- Best for
- Window screen, solar screen and patio screen frame
5 · Rolled form 7/16 × 1"
- Material thickness
- .025 heavy duty
- Detail
- Cambered (slightly bowed) to retain screen tension once installed
- Finishes
- White, bronze, almond, tan, mill
6 · Divider bar 5/16 × 5/8"
- Material thickness
- .025 screen frame
Minimum order 20 pieces. Lengths over 8' require freight shipping. Tell us the job and we will work out what you actually need.
