SCREAM FRAME & COMPONENTS
When it comes to screens, “CT Enclosures and screens LLC” can help you stand out against the competition with a variety of sizes, aesthetics, meshes and performance capabilities.
A wide range of window screen frame colors are available and varies by size of the Aluminum screen frame. Aluminum Screen Frames – Cut to Size Window Screen Frame is available in several sizes and colors. Standard 3/4″ wide frame for lighter weight materials such as fiberglass screen, aluminum screen wire
Order your Aluminum Screen Frames today!
EXTRUDED FRAMES
1) Extruded Screen Frame 5/16 x 3/4”
- Material thickness: .025 Screen Frame
Shipping Length: 12’ - Great solution where larger sizes are required. Available in almond, bronze, mill and white.
Disclaimer: If desired length is over 8’ freight shipping is required. Minimum Order 20 Pieces
![screen rooms Wallingford, CT](https://irp-cdn.multiscreensite.com/51833fa0/dms3rep/multi/thumbnail/1_Screen%20frame%205_AkwxHZNjTB229AFq7uNu-105x159.16%20x%203.4%20extruded.jpg)
White
Bronze
Almond
Mill
Hartford Green
Extruded Screen Frame 7/16 x 1”
2) Extruded Screen Frame 7/16 x 1”
- Material thickness: .062 Screen Frame
Shipping Length: 12’ - Ideal for larger window openings and other commercial applications.
Disclaimer: If desired length is over 8’ freight shipping is required. Minimum Order 20 Pieces
![outdoor screens Wallingford, CT](https://irp-cdn.multiscreensite.com/51833fa0/dms3rep/multi/thumbnail/2_frame-pic6_QtNvfJSJSb24KFPTz4SW-105x159.png)
White
Bronze
Clear satin anodized
ROLLED FORM FRAMES
Rolled Form 5/16 x 3/4”
3) Rolled Form 5/16 x 3/4”
- Material thickness: .0155
- For use in screen fabrication.
Disclaimer: If desired length is over 8’ freight shipping is required. Minimum Order 20 Pieces
![porch screens Wallingford, CT](https://irp-cdn.multiscreensite.com/51833fa0/dms3rep/multi/thumbnail/3_frame-pic8_Xun9GtK3TX2Yi22czhXZ-105x159.png)
Rolled Form - 7/16 x 3/4”
4) Rolled Form – 7/16 x 3/4”
- Material thickness: .0155
- Window Screen, Solar Screen and Patio Screen frame. For use in screen fabrication. Standard Screen length is 12’2″
Disclaimer: If desired length is over 8’ freight shipping is required. Minimum Order 20 Pieces
![screen contractor Wallingford, CT](https://irp-cdn.multiscreensite.com/51833fa0/dms3rep/multi/thumbnail/4_frame-pic10_AM0qoi8TB202f3jQSjWh-105x159.png)
Rolled Form 7/16 x 1”
5) Rolled Form 7/16 x 1”
- Material thickness: .025
- HD Window Screen Frame is made of heavy .025 mill thick, roll formed aluminum.
- It is cambered (slightly bowed) to retain screen tension when installed.
Disclaimer: If desired length is over 8’ freight shipping is required.
![screen enclosures Wallingford, CT](https://irp-cdn.multiscreensite.com/51833fa0/dms3rep/multi/thumbnail/5_simplicity_yLDvE339SgSacNcH9fuW-105x159.gif)
White
Bronze
Almond
Tan
Mill
5/16 x 5/8" Divider Bar .025 Screen Frame
6) 5/16 x 5/8″ Divider Bar .025 Screen Frame
- Screen Frame Center bar (Divider Bar) adds extra support to large size screens for improved rigidity and strength.
- It is made of .025 mill thick, roll formed aluminum and is not cambered.
Disclaimer: If desired length is over 8’ freight shipping is required. Minimum Order 20 Pieces
![screen frames Wallingford, CT](https://irp-cdn.multiscreensite.com/51833fa0/dms3rep/multi/thumbnail/6_divider_bar_K3bkFvihQWqjeeZBmb7z-105x159.gif)
Lipped Frame 3/8 x 15/16" Inside Spline Groove
7) Lipped Frame 3/8 x 15/16″ Inside Spline Groove
- Typical Applications Include Inset Flush-Mounting of Screens for Patio or Porch Installations.
- Installs and Removes Easily with Screen Clips
.020″ (.51 mm) Wall Thickness. - Matching Square Cut Plastic Lip Corners Available.
Disclaimer: If desired length is over 8’ freight shipping is required. Minimum Order 20 Pieces
![screen rooms Wallingford, CT](https://irp-cdn.multiscreensite.com/51833fa0/dms3rep/multi/thumbnail/7_lip_Zo23ftVYTeZ2JaRTdN9w-105x159.gif)
